High Power High Performance electric outboard systems by Explomar: 70 HP - 1200 HP
Thrilling, intelligent, and eco-friendly boating experiences
with our fully electric propulsion systems
Lightest 300 HP electric outboard in its class
First marine use of axial-flux motor technology for electric propulsion
Distributed control of twin system for smart functions
Explore More Request a Brochure
EXPLOMAR ELECTRIC OUTBOARD SYSTEMS: 70 – 1200 HP
WAVE 70+ HP ELECTRIC OUTBOARD MOTOR SYSTEM
ELECTRIC OUTBOARD MOTOR
Peak Power: 80kW • Continuous Power: 40kW • X-pin flat-wire motor for lighter weight
NMC BATTERY SI-60*2
Capacity 120kWh • Weight 720kg • Pack density ≥165Wh/kg
SMART CAPTAIN CONTROL SYSTEM
CAN2.0b • Remote/Tiller control • Deep integration, simple and easy to use
CHARGERS
Portable charger: 7KW • Input Voltage Range: 230V±10%
Movable charger: 40KW • Input Voltage Range: 400V±10%
Find out more: WAVE 70+ Request a Quote
WAVE 150+ HP ELECTRIC OUTBOARD MOTOR SYSTEM
ELECTRIC OUTBOARD MOTOR
Peak Power: 150kW • Continuous Power: 100kW • Axial Flux Motor technology
NMC BATTERY SI-90
Capacity 120kWh • Pack density ≥165Wh/kg • 1C charging
Estimated Energy Consumption: 2 kWh/km
Approximate Energy Equivalent: 60-Liter Gasoline
SMART CAPTAIN CONTROL SYSTEM
CAN2.0b • Control box, steering wheel, IP67-rated 12-inch touchscreen included
CHARGERS
Portable charger: 7KW • Input Voltage Range: 230V±10%
Movable charger: 40KW • Input Voltage Range: 400V±10%
Dual Gun Charging System: 120 KW • Input Voltage Range: 400V±10%
Find out more: WAVE 150+ Request a Quote
WAVE 300 HP ELECTRIC OUTBOARD MOTOR SYSTEM
ELECTRIC OUTBOARD MOTOR
Peak Power: 225kW • Continuous Power: 150kW • High performance no-clutch gearbox
NMC BATTERY SI-90 x 2 OR SI-90 x 3
Capacity 180kWh / 270 kWh • Pack density ≥165Wh/kg • Robust power: 540V
— OR—
HEDB 240 – SEMI SOLID BATTERY
Capacity: 240 kWh • Weight : 1,218 kg
Estimated Energy Consumption: 2.5 kWh/km
Approximate Energy Equivalent: 100 / 180 Liter Gasoline
SMART CAPTAIN CONTROL SYSTEM
CAN2.0b • Control box, steering wheel • High-speed driving direction protection
CHARGERS
Portable charger: 7KW • Input Voltage Range: 230V±10%
Movable charger: 40KW • Input Voltage Range: 400V±10%
Dual Gun Charging System: 120 KW • Input Voltage Range: 400V±10%
Find out more: WAVE 300 HP Request a Quote
600 HP: 8-15m BOATS (26 – 49 ft)
ELECTRIC OUTBOARD MOTORS: TWIN 300 HP
Peak Power: 450kW • Continuous Power: 300kW • High performance no-clutch gearbox
NMC BATTERY SI-90 x 4 OR SI-90 x 6
Capacity: 360kWh / 540 kWh • Weight: 2596 kg / 3676 kg
— OR —
HEDB 240 TWIN – SEMI SOLID BATTERY
480kwh • Pack density: 240wh/kg • Weight: 2436 kg
Estimated Energy Consumption: 3.75 kWh/km
SMART CAPTAIN CONTROL SYSTEM
CAN2.0b • Steer-by-wire and trim technology for precise control • Intelligent torque management system
Find out more: 600 HP Request a Quote
1200 HP: 10-15m BOATS (32 – 49 ft)
ELECTRIC OUTBOARD MOTORS: 300 HP x 4
Peak Power: 900kW • Continuous Power: 600kW • High performance no-clutch gearbox
NMC BATTERY SI-90 x 8
Capacity: 720kWh • Weight: 4320 kg • 1C charging • Battery cooling & heating temperature control
Estimated Energy Consumption: 7.5 kWh/km
Approximate Energy Equivalent: 480 Liter Gasoline
SMART CAPTAIN CONTROL SYSTEM
CAN2.0b • Steer-by-wire and trim technology for precise control • Intelligent torque management system
CHARGERS
Portable charger: 7KW • Input Voltage Range: 230V±10%
Movable charger: 40KW • Input Voltage Range: 400V±10%
Dual Gun Charging System: 120 KW • Input Voltage Range: 400V±10%
Find out more: WAVE 1200 HP Request a Quote
CONTACT US FOR MORE INFORMATION
